Refrigerant Pump, Airborne Electronics Cooling
P-328, 328-D-001
Features & Benefits
The challenges of pumping a refrigerant are unique, from the subtleties of moving liquid near its saturation temperature to efficiently pumping such a low-viscosity fluid. Cascon developed the technology and know how to design products that reliably meet these challenges for cooling applications including airborne power electronics.
- 400 Hz AC Drive Motor
- Flooded Motor (No rotary Seals)
- Axial inducer 1st stage and Centrifugal Impeller 2nd Stage
- Ultra-low inlet pressure capability
Performance Parameters
- Part Number
- 328-D-001
- Application Fluid
- R1234z(e), R134a
- Supply Operating Voltage
- 115 VAC / 400 Hz
- Drive Type
- Electric
- Pump Type
- Centrifugal
- Weight
- 10.5 lbs
- Circuits
-
Circuit Max Flow Max Pressure Operating Speed Single-circuit 8.85 gpm 45 psi 11750 rpm - Inlet Pressure, Above Saturation
- 1.2 psia
- Fluid Temp
- 64 DegC
Airborne Electronics Cooling
